Automotive Tester / Handheld Ignition-Tachometer PCE-AT 5

PCE-AT 5

Automotive Tester / Handheld Ignition-Tachometer PCE-AT 5

PCE-AT 5

Art. number:
Date published 06.02.2024
Unavailable
VAT not included in the price
PCE-AT 5 Automotive Tester / Handheld Ignition-Tachometer
Measures revolutions in one-cylinder two-stroke and eight-cylinder four-stroke combustion engines with electric ignition starters

The PCE-AT 5 automotive tester / handheld ignition-tachometer is a portable compact device used to measure revolutions per minute (rpm) in one-cylinder two-stroke and eight-cylinder four-stroke combustion engines with electric ignition starters. The PCE-AT 5 handheld automotive ignition-tachometer features an easy-to-read, backlit digital LCD display and flashlight functionality for low-light applications. When the inductive clip is placed on the ignition cable, revolutions are measured quickly and easily. Compatible with motorcycles, cars, trucks and more, the PCE-AT 5 rotation meter is a versatile tool for use in garages, repair shops, factories and research and development (R&D) laboratories alike.

HIGHLIGHTS

- Measures revolutions in all common combustion engines with electric ignition starters
- Compatible with one-cylinder two-stroke engines as well as eight-cylinder four-stroke engines
- 1.1 m / .04 in cable with inductive clip to be placed on ignition cable
- 6-digit backlit LCD display and flashlight functionality for low-light applications
- Durable ABS plastic housing ensures longevity
Measurement range 100 ... 20000 rpm
Resolution 1 rpm
Accuracy ± 10 rpm
Measurement interval 0.5 seconds
Power supply 1 x 9V battery
Operating temperature  0 ... 50ºC / 32 ... 122ºF
Housing ABS plastic
Display 6-digit 22 mm / .9 in LCD
Dimensions 160 x 58 x 39 mm / 6.3 x 2.3 x 1.5 in
Weight 177 g / < 1 lb
datasheet-pce-at-5.p... PDF, 187.8 KB Download
