Compact, dual-gas monitor DuoIQ
DUOIQ
DuoIQ is a compact, dual-gas monitor designed to provide workers with versatile, reliable protection against multiple hazards. Built with a long-lasting rechargeable battery life and every major sensor technology, DuoIQ provides safety in environments where detecting two gases is critical but equipment size and cost need to be optimised.
optimised for safety and compliance
-
DuoIQ integrates seamlessly with
Crowcon Connect for real-time
monitoring, compliance tracking, and
asset management -
Improves safety and ensures regulatory requirements are met
-
Effortlessly store and retrieve calibration certificates in Crowcon Connect to simplify audits
FEATURES & BENEFITS
Dual-gas detection
The only dual-gas detector with the capability to detect a wide range of gas combinations, providing flexibility for diverse applications without the need for bulky, multi-gas devices.
Extended battery life
DuoIQ boasts one of the longest battery lives of any dual-gas monitor, reducing recharge frequency and operational downtime. It offers up to one-month of use based on standard 8-hour shifts*. Between-shift charging keeps devices operational, with full recharge achieved in under 3 hours.
Pre-calibrated sensor trays
DuoIQ’s sensor trays are easy to swap, eliminating the need to send the device back to the manufacturer for maintenance. Additionally, the plug-and-play modular design provides flexibility to target different gases.
Comprehensive sensor technology
DuoIQ features unique sensor combinations, made possible by its wide variety of sensor technologies, including electrochemical, infrared (IR), pellistor, and long-life oxygen (O2) sensors.
Optimised for safety & compliance
DuoIQ integrates seamlessly with Crowcon Connect for real-time monitoring, compliance tracking, and asset management, improving safety and ensuring regulatory requirements are met. Effortlessly store and retrieve calibration certificates in Crowcon Connect to simplify audits.
Lightweight, compact design
With its compact design, DuoIQ delivers reliable performance in a lightweight form - measuring just over 10cm in height and weighing only 135g**, ensuring portability and ease of use.
Bluetooth® & NFC connectivity
With Bluetooth ® and Near Field Communication (NFC) connectivity, DuoIQ can push data to Crowcon Connect via IQhub. This enables live data streaming, remote configuration, and detailed insights for enhanced safety and device performance.
One button for multiple functions
Single-button operation simplifies the user experience with quick, intuitive control, reducing complexity and learning curves, while making the device more widely accessible.
| Size | Standard: 96 x 55 x 32 mm Deep tray: 106 x 55 x 32 mm |
| Weight | 135g (Weight may vary depending on configuration) |
| Durability | 6m drop test |
| Response Time (T90) | <10s (sensor dependent) |
| Alarms | Visual, vibrating, audible (95dB at 30cm), low/high, TWA, STEL |
| Display | Backlit segment display |
| Data Logging | Up to 500 event logs |
| Power & Battery |
Tox / O2 | tox : 7 days, (20 days at 8 hour shifts) Recharge time: 0-80% 2 hours; 0-100% <3 hours |
| Sampling | None |
| Operating Temperature Range | -20 to +55°C (-4 to +131°F) |
| Humidity | 0-95%RH |
| Ingress protection | IP66 & IP68 |
| Approvals |
CSA US: Class I, Division 1, Groups A, B, C, D T4* *Pending |
| Calibration & Maintenance | Automatic bump tests (<10 seconds)and calibrations (<30 seconds) through IQhub; Manual bump and calibrations through device and PC software |
| Accessories | Power cable (device to USB-A & USB-C); Flow plate; IQhub |
| Connectivity | NFC & Bluetooth® (optional) required for connection to Crowcon Connect App for live data and configuration |
| Crowcon Connect | Cloud-hosted web application for safety monitoring and asset management, offering real-time alarms, compliance dashboards, location tracking, device configurations, and essential reporting |
| Sensors | Electrochemical, IR, Pellistor and Long life O2 |
| Languages | English |
| Warranty | 2 years (sensor warranty separate) |
| Gas | Range | Resolution |
|---|---|---|
| Ammonia (NH3) | 0-100ppm | 0.1ppm |
| Butane (C4H10) | 0-100% LEL | 1% LEL |
| Carbon Dioxide (CO2) | 0-2% volume | 0.01% volume |
| Carbon Monoxide (CO) | 0-250ppm | 1ppm |
| Chlorine (Cl2) | 0-10ppm | 0.1ppm |
| Hydrogen Sulphide (H2S) | 0-100ppm | 0.1ppm |
| Methane (CH4) | 0-100% LEL | 1% LEL |
| Nitrogen Dioxide (NO2) | 0-20ppm | 0.1ppm |
| Oxygen (O2) | 0-25% volume | 0.1% volume |
| Ozone (O3) | 0-1ppm | 0.1ppm |
| Sulphur Dioxide (SO2) | 0-20ppm | 0.1ppm |
